4.5" 4.0MP HD-IP IR Medium Speed Dome Camera
Features:*4.5" Total Metal body construction, IP66 rate protection*1/3" CMOS, 4.0 Megapixels, 10X optical zoom*HD-IP digital interface output, 4.0MP high definition image*PWM function, intelligent IR illumination & power consumption is variable, dependant the zoom factor*IR distance 5......
Send Inquiry
Product Description
Features:
*4.5" Total Metal body construction, IP66 rate protection
*1/3" CMOS, 4.0 Megapixels, 10X optical zoom
*HD-IP digital interface output, 4.0MP high definition image
*PWM function, intelligent IR illumination & power consumption is variable, dependant the zoom factor
*IR distance 50M
*Support P2P function
*ONVIF2.2
*OSD menu is available
*ONVIF2.4 compatible;
*Compatible with DAHUA , HIKVISION , XM
*Compatible with AXXON , Milstone
Specification:
*4.5" Total Metal body construction, IP66 rate protection
*1/3" CMOS, 4.0 Megapixels, 10X optical zoom
*HD-IP digital interface output, 4.0MP high definition image
*PWM function, intelligent IR illumination & power consumption is variable, dependant the zoom factor
*IR distance 50M
*Support P2P function
*ONVIF2.2
*OSD menu is available
*ONVIF2.4 compatible;
*Compatible with DAHUA , HIKVISION , XM
*Compatible with AXXON , Milstone
Specification:
| Sensor | 1/3" 4.0M OV4689 CMOS |
| Total pixels | 4.0 Megapixels |
| Output Pixel | 2304x1296@30fps 2592x1520@22fps 2592x1944@15fps |
| Lens | 10X f=5.1mm(W) ~ 51mm(T) |
| Iris | F1.6~F1.8 |
| Min. illumination | Color: 0.05Lux\ B/W: 0.01Lux |
| D/N | IR-CUT |
| AGC | Auto/manual |
| WB | Auto/manual/indoor/outdoor |
| Shutter | 1/2 - 1/20,000s |
| S/N Ratio | ≥50dB |
| Communications Protocol | TCP/IP,HTTP,NTP,IGMP,DHCP,UDP,SMTP,RTP,RTSP,ARP,DDNS,DNS,HTTPS,P2P |
| Software Control | IE, CMS, Management Platform |
| Mobile View(optional) | Support Windows, iPhone platform smartphone |
| Horizontal Rotation Speed | 0.02°/s-45°/s |
| Horizontal Rotation Range | 360° |
| Tilt Rotation Speed | 0.02°/s-80º/s |
| A-B Scan | User programmable |
| A-B Scan Speed | 1-9 levels setting available |
| Dwell Preset | 1-60s interval available |
| Preset Points | 220 |
| Go to Preset Speed | 01-64 levels available |
| PWR On Action | Memory/Tour 1/360° scan/A-B scan/Preset 1-8/None |
| Park Time | 01-60mins available |
| Preset Points | 220 |
| Guard Tours | 3 groups |
| Guard Points | Max.16 points, dwell time user selectable |
| Operating temperature | Indoor: 0°~ +40° Outdoor: -40°~ +60° |
| Pan and Tilt position display | Support |
| Auto Control IR LED | PWM |
| LEDs | Array 42Mil |
| IR distance | up to 50 meters |
| Support ambient light detection | IR illumination on 1-15 grades selectable; |
| Humidity | ≤95% Non Condensing |
| Power | DC12V 3A |
| Consumption | < 15W |
| Lightning Protection | Transient voltage 6000V |
| Related validation | IP66,CE,FCC,RoHs |
